Hydraulic Manifold - Sequence, Through Port 1 with Gauge Port
| Modifiers | Ports |
| KJ5, /S | Ports 1 & 2: 1 1/4" Code 62; Port 3: SAE 6; Gage Port: 1/4" NPTF; |
| KJ5/M, /T | Ports 1 & 2: 1 1/4" Code 62; Port 3: 1/4" BSPP; Gage Port: 1/4" BSPP; |
| Body Type | Line mount |
| Interface | 1.25 SAE C62 |
| Body Features | Through port 1 with gauge port |
| Mounting Hole Thread | .375-16 UNC - 2B in. |
| Mounting Hole Thread | M10x1.5 - 6H (metric models) |
| Mounting Hole Depth | .62 in. |
| Mounting Hole Quantity | 2 |
| Open Cavities | 1 |
| Cavity | T-19AU |
| Port Size | 1 1/4" Code 62 |
| Model Weight | 7.01 lb. |
