Sub Plate Manifold - Check, On P

Sub Plate Manifold - Check, On P
Port Designators
Modifiers Ports
ZAW Ports A, B, P, T: SAE 10;
Parameter
Body Type Subplate
Interface ISO 03
Body Features On P
Mounting Hole Diameter .34 in.
Mounting Hole Depth Through
Mounting Hole C'bore Diameter .50 in.
Mounting Hole C'bore Depth .38 in.
Mounting Hole Quantity 2
Open Cavities 1
Cavity T-5A
Port Size SAE 10
Model Weight 1.53 lb.
Face
Sub Plate Manifold - Check, On P
Sub Plate Manifold - Check, On P Sub Plate Manifold - Check, On P Sub Plate Manifold - Check, On P Sub Plate Manifold - Check, On P
